ZM16A Series Medical-Grade High-Density Waterproof Circular Connector | 108/208 Core IP68 PA66 Material | Gold-Plated Copper Alloy Contacts with Snap-On Locking

🚀 Product Overview

In the field of medical electronic devices, connection stability directly impacts diagnostic data accuracy and patient safety. This ZM16A Series high-density circular connector is specifically designed for medical instruments, life support systems, and diagnostic equipment, meeting the stringent requirements of the medical industry for electrical connections with military-grade reliability.

Circular Push-pull Connector Used for Cable

This connector features a high-strength PA66 material housing with excellent chemical resistance and mechanical strength. It offers two high-density contact configurations—108 cores and 208 cores—meeting the massive signal transmission requirements of complex medical equipment. Gold-plated copper alloy contacts ensure stable and reliable signal transmission, the IP68 waterproof rating effectively protects against dust and disinfectant ingress, while the snap-on locking design provides quick, secure, and anti-loosening connections. As an OEM custom product, we can flexibly match your equipment interface requirements.

🔧 Core Features

Waterproof Connector

Feature	Advantage
Gold-Plated Copper Alloy Contacts	Ensures durability and reliability in electrical connections, reduces contact resistance, enables high-fidelity transmission of weak bioelectrical signals, with mating cycle life exceeding 1000 insertions
IP68 Waterproof Rating	Completely dust-tight and suitable for long-term immersion, effectively resists liquid splashes and medical disinfectant corrosion, adapting to stringent hospital cleaning and disinfection procedures
Snap-On Locking Design	Quick connect/disconnect operation with secure locking and clear tactile feedback, preventing accidental disconnection from pulling, enhancing safety in medical operations
PA66 High-Strength Housing	Material offers excellent chemical resistance (tolerates common disinfectants such as alcohol and hydrogen peroxide), high-temperature resistance, and mechanical impact resistance, ensuring no deformation or cracking during long-term use
108/208 Core High-Density Configuration	Supports simultaneous multi-channel signal transmission, meeting complex connection requirements from multi-parameter monitors to advanced imaging equipment, significantly saving equipment panel space
OEM Customization Service	Pin definitions, cable assemblies, color coding, and keyway positions can be customized according to your medical equipment requirements, perfectly matching your product design

⚙️ Technical Specifications

Medical Connector

Parameter Attribute	Detailed Specification
Product Series	ZM16A Series (Medical-grade high-density circular connector)
Core Configuration	108 Cores / 208 Cores (High-density arrangement)
Contact Material	Copper alloy, gold-plated (15μ"+ thick gold, ensuring stable transmission of weak signals)
Housing Material	High-strength PA66 (Nylon 66, chemical-resistant, high-temperature resistant, flammability rating UL94 V-0)
Ingress Protection	IP68 (Dust-tight, suitable for long-term immersion, resistant to disinfectant soaking)
Locking Method	Snap-on quick locking (Push-pull design with locking feedback)
Mounting Method	Socket panel mounting (Flange fixing)
Rated Voltage	Depends on core configuration (High-voltage versions available upon request)
Rated Current	Depends on core configuration
Insulation Resistance	≥5000MΩ (Typical)
Contact Resistance	≤5mΩ
Operating Temperature	-40℃ to +105℃
Mechanical Life	>1000 Mating Cycles
Salt Spray Test	≥96 hours (Optional)
Applicable Standards	Complies with medical electrical equipment safety standard IEC 60601-1 and biocompatibility requirements

🏭 Medical Application Areas

This high-density medical-grade connector is the core interface component for the following medical devices:

Application Field	Specific Equipment Examples
Patient Monitoring	Lead interfaces for multi-parameter monitors (ECG/SpO2/NIBP/Temp), electroencephalographs (EEG), electromyographs (EMG)
Medical Imaging	Portable ultrasound probe interfaces, C-arm image data transmission, DR detector signal connections
Life Support	Multi-parameter sensor modules for ventilators, anesthesia gas monitoring interfaces, ECMO systems
Surgical Equipment	Cable connections for electrosurgical units, ultrasonic scalpels, surgical navigation systems
Rehabilitation Equipment	Control and feedback interfaces for electric hospital beds, rehabilitation robots, physical therapy devices
Laboratory Instruments	Data and power interfaces for biochemical analyzers, flow cytometers, gene sequencers

✅ Why Choose Us?

Waterproof Connector

1. Medical-Grade Quality Assurance

Product design strictly complies with IEC 60601-1 medical electrical equipment safety standards. Contacts feature thick gold plating technology, ensuring high-fidelity transmission of weak bioelectrical signals. Complete material certifications, biocompatibility reports, and test data are available upon request.

2. Top-Level Environmental Protection

The perfect combination of IP68 protection rating and PA66 corrosion-resistant housing ensures long-term stable operation of the connector in frequently cleaned and disinfected medical environments, effectively resisting erosion from common disinfectants such as alcohol, hydrogen peroxide, and glutaraldehyde.

3. High-Density Integration Design

The 108-core and 208-core ultra-high density configurations enable massive signal transmission within limited panel space, supporting the miniaturization and lightweight development of medical equipment. Precision insulator design ensures no signal crosstalk between adjacent pins.

4. Flexible OEM Customization

We offer comprehensive OEM customization services:

Custom pin arrangements and electrical definitions
Custom cable assemblies and backshell accessories
Custom housing colors and laser marking
Custom keyway positions and mechanical coding

5. Quick Response and Technical Support

From selection consultation and drawing confirmation to sample testing and mass production supply, we provide one-on-one support from dedicated medical industry engineers, ensuring efficient project progress.

Build reliable connections for life science technology. Contact us today for samples and technical white papers!

Note: Product complies with medical electrical equipment safety and biocompatibility requirements. For detailed specifications, 3D drawings, and certification documents, please contact our dedicated medical industry customer service.
