High Voltage Connectors: Essential for Advanced Industrial Applications
The Critical Role of High Voltage Connectors
High voltage connectors play a crucial role in industries that rely on efficient and safe power transmission. From push pull connectors used in medical imaging systems to high voltage circular connectors in industrial applications, these connectors are engineered to handle electrical voltages beyond standard limits.
In industries like medical, industrial, automotive, and scientific research, these connectors are essential for ensuring safety, reliability, and operational efficiency.
Key Advantages of High Voltage Connectors
Below are the key advantages that make Linkhive high voltage connectors stand out:
| Advantage | Description |
|---|---|
| High Voltage Rating | Rated for voltages up to 25kV, making them ideal for applications such as push pull connectors and high voltage connectors in medical and industrial systems. |
| Robust Construction | Built from high-quality materials like PPS/PEEK, designed to withstand moisture, mechanical stress, and extreme temperatures. |
| Push-Pull Self-Latching Mechanism | Ensures fast, secure, and reliable mating, minimizing manual effort while providing tight, stable connections for circular connectors in various environments. |
| High Shielding Efficiency | Offers up to 75dB shielding at 10MHz, ensuring minimal interference and maximum signal integrity, particularly in high-frequency applications. |
| Customizable Pin Layouts | Provides flexibility for specific application needs, ensuring precise and reliable connections for industrial, medical, and scientific equipment. |
Applications of High Voltage Connectors
High voltage connectors are used across various industries. Below are some key areas where these connectors are essential:
1. Medical Imaging Equipment
X-ray machines and MRI scanners require connectors that can safely handle high voltages without compromising safety or performance.
Push pull connectors are preferred for easy connection/disconnection in medical systems.
2. Industrial Power Supply Systems
Used in power transmission systems and industrial machinery, high voltage connectors provide stable power delivery in harsh environments.
These connectors are ideal for equipment requiring circular connectors for safe, reliable energy transfer.
3. Electric Vehicles (EVs) and Charging Stations
High voltage connectors are integral in electric vehicle charging stations for safe and efficient power transfer.
The push pull mechanism ensures secure connections in high-voltage automotive systems.
4. Military and Aerospace
Connectors used in military and aerospace applications must perform reliably under extreme conditions, handling high voltage with durability and safety.
5. Scientific Research
High voltage connectors are used in laboratory equipment, such as particle accelerators, where precision power handling is crucial.
Detailed Specifications: What Makes Linkhive High Voltage Connectors Stand Out
| Specification | Value |
|---|---|
| Maximum Humidity | Up to 95% at 60°C/140°F |
| Locking Type | Push pull connector |
| Endurance | 5000 cycles |
| Shock Resistance | 100g |
| Salt Spray Corrosion Test | 96hr |
| Resistance to Vibration | 15g (10Hz–2000Hz) |
| Shielding Efficiency | 75dB (10MHz); 40dB (1GHz) |
| Working Temperature | -55°C to +125°C |
| Test Voltage (Contact-Contact) | 1450V |
| Test Voltage (Contact-Shell) | 1000V |
| Insulation Resistance | ≥5000MΩ (600V DC) |
| IP Rating | IP68 (Dustproof & Waterproof) |
These connectors are built for the most demanding environments, providing reliable electrical connections under extreme conditions.
F-Series and S-Series High Voltage Connectors
Linkhive’s F-series and S-series provide high-voltage connectors designed for both standard and specialized applications. Here’s a comparison of these two series:
F-Series High Voltage Connectors
| Feature | Details |
|---|---|
| Voltage Rating | Up to 25kV |
| Ideal for | Medical, industrial, and scientific applications |
| Material | Coaxial construction with enhanced shielding |
| Mating Type | Push pull connectors |
| Test Voltage | 1450V (Contact-Contact) |
S-Series High Voltage Connectors
| Feature | Details |
|---|---|
| Voltage Rating | Up to 25kV |
| Ideal for | High dielectric strength and compact designs |
| Material | PTFE insulation for enhanced performance |
| Mating Type | Multi-pin layouts for versatile applications |
| Test Voltage | 1450V (Contact-Contact) |
Both series are available in push pull connector configurations, ensuring secure and efficient connections.
High Voltage Connector Applications Overview
| Industry | Application Examples |
|---|---|
| Medical Imaging | MRI scanners, X-ray machines, CT scanners |
| Industrial Systems | Power transmission systems, Heavy machinery |
| Electric Vehicles | Charging stations, Electric vehicle connectors |
| Military | Military vehicles, Aerospace systems |
| Scientific Research | Laboratory equipment, Particle accelerators, Diagnostic tools |
The Future of High Voltage Connectors
As industries continue to advance, high voltage connectors will remain a critical component in ensuring that electrical systems operate safely and efficiently. The integration of push pull connectors and circular connectors into a wide range of applications—from medical devices to electric vehicles—demonstrates their growing importance in the modern technological landscape.
By choosing Linkhive’s high voltage connectors, industries ensure reliability, safety, and durability, making these connectors essential for enabling technological innovation and operational success in a range of applications.
With custom configurations, rugged design, and superior electrical performance, Linkhive's connectors are ready to support the next generation of high-voltage systems.
